Oscilloscope

The Moku Oscilloscope features up to four high-speed, ultra-low-noise input channels with an analog bandwidth of up to 600 MHz and a sample rate of up to 5 GSa/s. For maximum flexibility, we offer 12-bit or fully integrated 10-bit and 18-bit blended ADCs to cover a broad spectrum, providing class-leading input noise performance of 30 nV/√Hz at 100 Hz with a high dynamic range. Leverage the built-in four-channel Waveform Generators to quickly produce various waveforms with a maximum bandwidth of 500 MHz.

Download datasheet

The Moku Oscilloscope is easy to use and offers a range of advanced capabilities to optimize your experiment — at the most cost-effective price in the industry.

A man working on the computer with moku waveform generator

Easy-to-use, high-performance oscilloscope measurements

Built on a powerful Xilinx FPGA, the Moku Oscilloscope delivers the ultimate combination of versatility and performance. With a high-quality analog front end, the Oscilloscope makes signal monitoring more intuitive than ever before. With Moku:Pro, our blended ADC technology lets you measure with class-leading input noise performance of 30 nV/√Hz at 100 Hz and a high dynamic range.

Try the software
Oscilloscope waveform parameters

Unlock greater insights with fully integrated Waveform Generators

Stimulate a system and measure its response simultaneously with up to four integrated Waveform Generators, capable of producing sine waves at up to 500 MHz, and square, triangle, and pulse waves at up to 150 MHz.

oscilloscope preset measurements

Automatic and manual measurement options for maximum flexibility

Select from a wide range of preset measurements, including a variety of visualization tools including measurement trends and histograms. Add draggable cursors to set custom measurements for voltage or time between points.

oscilloscope real time math operations

Configurable math channel for total customization

Customize your measurements and perform real-time math operations such as addition, subtraction, multiplication, division, and FFT with support for arbitrary functions.

Lock-in amplifier's LabVIEW boxed

Engineered to work seamlessly with your preferred APIs

API integration with Python, MATLAB, and LabVIEW allows straightforward automation of your Moku device in complex setups or for repetitive tasks. Save your measurements, screenshots, traces, and other settings locally or to your preferred cloud app. You can also send work to yourself or colleagues within the Moku app.

Engineered for demanding applications

Use the Moku Oscilloscope to accelerate development timelines with speed and flexibility unmatched by any other instrument in its class.

Automated system test

Circuit design and characterization

Jitter/clock analysis

Signal monitoring and analysis

System test and debug

Integrates seamlessly with your tech stack

Specifications and technical documents

The Moku Oscilloscope runs on Moku:Pro, Moku:Lab, and Moku:Go. Compare the specifications to choose the right device for your application.

mokupro
mokulab

Moku:Pro

Learn more

Moku:Lab

Learn more

Moku:Go

Learn more

Technical specifications

Channels

4 inputs / 4 outputs

2 inputs / 2 outputs

2 inputs / 2 outputs

Digital I/O

TTL external trigger

TTL external trigger

16 channels

Sampling rate

Up to 5 GSa/s

500 MSa/s

125 MSa/s

Memory depth

60 million points

4 million points

4 million points

Bandwidth

600 MHz

200 MHz

30 MHz

ADC resolution

10-bit + 18-bit blended

12-bit

12-bit

10 MHz reference

Yes

Yes

No

Software & utilities

Windows, macOS, iPadOS, and visionOS apps
API support for Python, MATLAB, and LabVIEW

Windows, macOS, iPadOS, and visionOS apps
API support for Python, MATLAB, and LabVIEW

Windows, macOS, iPadOS, and visionOS apps
API support for Python, MATLAB, and LabVIEW

Documentation

Datasheets

Moku:Pro Oscilloscope Datasheet
Moku:Pro Hardware Datasheet

Moku:Lab Oscilloscope Datasheet
Moku:Lab Hardware Datasheet

Moku:Go Oscilloscope/Voltmeter Datasheet
Moku:Go Hardware Datasheet

User manuals

Moku:Pro Oscilloscope User Manual

Moku:Lab Oscilloscope User Manual

Moku:Go Oscilloscope/Voltmeter User Manual

Specs

Moku:Pro Oscilloscope Specs

Moku:Lab Oscilloscope Specs

Moku:Go Oscilloscope Specs
